K Hom Thermocouple

Hom K Thermocouple muab kev ua haujlwm kub tshaj plaws. Nws muaj cov ceg zoo uas tsis yog hlau nplaum thiab tsis zoo ceg uas yog hlau nplaum. Hauv K hom Thermocouple tsoos puag hlau yog siv vim nws tuaj yeem ua haujlwm ntawm qhov kub thiab txias thiab tuaj yeem muab kev ua haujlwm kub tshaj plaws. Ib qho ntawm cov khoom siv hlau hauv K Hom Thermocouple yog Nickel, uas yog hlau nplaum hauv qhov xwm txheej.

Cov yam ntxwv uas pom los ntawm K Hom Thermocouple yog tias lawv tau txais qhov sib txawv ntawm cov zis thaum cov khoom sib nqus mus txog nws qhov Curie Point, nyob ib ncig ntawm 185 degree. K hom thermocouple ua haujlwm zoo heev hauv oxidizing cua ntawm qhov kub txog li 1260 degree (2300 degree F) thiab nws cov chav kawm kam rau ua yog ± 1.5 K ntawm -40 thiab 375 degree .

Hom K muaj lub neej ntev dua li Hom J raws li hom J Fe (hlau) hlau oxidizes sai, tshwj xeeb tshaj yog nyob rau hauv qhov kub thiab txias.

Lawv pheej yig.

Muaj lus teb ceev ceev.

Me me me thiab txhim khu kev qha.

Feem ntau siv ntawm qhov kub siab tshaj 540 degrees C.

Hauv K hom Thermocouple zoo ceg yog tsim los ntawm 90 feem pua ​​​​nickel, 10 feem pua ​​​​chromium thiab ceg tsis zoo yog tsim los ntawm 95 feem pua ​​​​nickel, 2 feem pua ​​​​ntawm txhuas, 2 feem pua ​​manganese thiab 1 feem pua ​​​​silicon. Cov no yog cov hom phiaj dav dav tshaj plaws thermocouple nrog qhov rhiab heev ntawm kwv yees li 41µV / degree.

Yuav kom nrhiav tau ntau yam ntawm cov thermocouple tsim nyog peb yuav tsum siv cov xaim tsim nyog vim cov xov hlau sib txawv ntsuas ntau qhov kub thiab txias. Ntawm plaub hom thermocouple loj, hom K npog qhov dav tshaj plaws:-

Thermocouple qib hlau, -454 txog 2,300F (-270 txog 1260 degree)

Extension hlau, 32 txog 392F ({2}} rau 200 degree)

Txuj: ntxiv /- 2.2 degree lossis ntxiv /-.75 feem pua

Tshwj xeeb txwv ntawm yuam kev: ntxiv /- l degree los yog 0.4 feem pua

Lawv feem ntau yog siv rau cov ntawv thov ntawm qhov kub siab tshaj 550 degree mus rau qhov siab tshaj plaws ua haujlwm siab ntawm thermocouple.

Lawv tau siv hauv ntau qhov kev lag luam xws li Hlau & Hlau los saib xyuas qhov kub thiab txias los ntawm kev ua cov hlau.

Siv rau kev ntsuas kub uas cuam tshuam nrog cov txheej txheem cov nroj tsuag xws li kev tsim tshuaj lom neeg thiab roj av refineries.

Siv rau Kev Ntsuas ntawm cov khoom siv cua sov kev nyab xeeb.

Hom K feem ntau yog siv rau hauv daim ntawv thov nuclear vim nws cov txheeb ze hluav taws xob hardness.
